Synthesis and analysis of an aplanatic mirror-lens system with axial symmetry

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

The problems of synthesis and analysis of an axisymmetric aplanatic mirror-lens system that transforms the spherical front of a source into a flat one are considered. Two methods have been developed for solving the problem of synthesizing the system’s generatrices: using a numerical procedure and the Kelleher formula, and also by reducing it to a differential equation with a retarded argument. Formulas are obtained for the eikonal in the aperture of the system when the source is displaced from the focus. The dependence of the mean square aberration of the eikonal on the system parameters has been studied and their optimal values have been found.

About the authors

A. S. Venetsky

Kotelnikov Institute of Radio Engineering and Electronics RAS

Author for correspondence.
Email: red@cplire.ru
Russian Federation, Mokhivaya Str. 11, build. 7, Moscow, 125009

V. A. Kaloshin

Kotelnikov Institute of Radio Engineering and Electronics RAS

Email: red@cplire.ru
Russian Federation, Mokhivaya Str. 11, build. 7, Moscow, 125009

Trinh Van Tuan

Moscow Institute of Physics and Technology (National Research University)

Email: red@cplire.ru
Russian Federation, Institutskii Lane 9, Dolgoprudny, Moscow region, 141700

References

  1. Schmidt B. //Centralzeitung fur Optik und Mechanik. 1931. V. 52. № 2. P. 25.
  2. Максутов Д. Д. Астрономическая оптика. 2-е изд. Л.: Наука, 1979.
  3. Михельсон Н. Н. Оптика астрономических телескопов и методы ее расчета. М.: Физматлит, 1995.
  4. Калошин В. А., Фролова Е. В. // Журн. радиоэлектроники. 2015. № 12. http://jre.cplire.ru/jre/dec15/19/text.pdf.
  5. Kelleher K. S.// J. Appl. Phys. 1950. V. 21. № 6. P. 573.
