An investigation of the electrical properties and microstructure of Ni/Ce0.8Gd0.2O2, composite-based anode for a solid oxide fuel cell fabricated by 3D printing

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

In this work, a series of planar anode billes for a solid oxide fuel cell based on NiO/Ce0.8Gd0.2O2 (NiO/GDC) was fabricated using the microdroplet 3D printing method with a pneumatic metering valve. The porosity and shrinkage coefficient during sintering of the anode billes, depending on the method of fabrication, have been investigated.

Anode billes were reduced in a hydrogen flow, and the effect of printing parameters on the morphological, structural, and electrochemical characteristics of NiO/Ce0.8Gd0.2O2 cermet was studied. The use of 3D printing was found to increase the porosity of the Ni/GDC composite from 7 to 23% as compared to that of the sample prepared by means of casting, while the value of electrical conductivity, (2.82 ± 0.06)·103 S/cm, remains high.

Full Text

Restricted Access

About the authors

A. D. Asmedianova

Institute of Solid State Chemistry and Mechanochemistry, Siberian Branch, Russian Academy of Sciences; Novosibirsk State University

Author for correspondence.
Email: asmedianova@gmail.com
Russian Federation, Novosibirsk; Novosibirsk

A. I. Titkov

Institute of Solid State Chemistry and Mechanochemistry, Siberian Branch, Russian Academy of Sciences

Email: asmedianova@gmail.com
Russian Federation, Novosibirsk

References

  1. Tai, X.Y., Zhakeyev, A., Wang, H., Jiao, K., Zhang, H., and Xuan, J., Accelerating Fuel Cell Development with Additive Manufacturing Technologies: State of the Art, Opportunities and Challenges, Fuel Cells, 2019, vol. 19, no. 6, p. 636.
  2. Лебедева, М.В., Яштулов, Н.А. Топливные элементы – характеристика, физико-химические параметры, применение. Учеб. пособие. М.: Мир науки, 2020. Сетевое изд., с. 17.
  3. Modak, C.D., Kumar, A., Tripathy, A., and Sen, P., Drop impact printing, Nat. Commun., 2020, vol. 11, p. 4327.
  4. Bagishev, A., Titkov, A., Vorobyev, A., Borisenko, T., Bessmeltsev, V., Katasonov, D., and Nemudry, A., Development of composite electrode materials based on nickel oxide for additive manufacturing of fuel cells, MATEC Web of Conferences, 2021, vol. 340, p. 1115.
  5. Bagishev, A.S., Mal’bakhova, I.M., Vorob’ev, A.M., Borisenko, T.A., Asmedianova, A.D., Titkov, A.I., and Nemudryi, A.P., Layer-by-Layer Formation of the NiO/CGO Composite Anode for SOFC by 3D Inkjet Printing Combined with Laser Treatment, Russ. J. Electrochem., 2022, vol. 58, p. 600.
  6. Lv, Z., Huang, X., and Liu, X., Effect of Fuel Depletion on Ni-YSZ Anode Supported Membrane Fuel Cell Under Different Discharge Modes, ECS Trans., 2021, vol. 103, no. 1, p. 1059.
  7. Hussain, S. and Yangping, L., Review of solid oxide fuel cell materials: cathode, anode, and electrolyte, Energy Transitions, 2020, vol. 4, p.113.
  8. Gorte, R.J. and Vohs, J.M., Novel SOFC anodes for the direct electrochemical oxidation of hydrocarbons, J. Catalysis, 2003, vol. 216, p. 481.
  9. Steele, B.C.H., Appraisal of Ce1 – yGdyO2 – y/2 electrolytes for IT-SOFC operation at 500 оC, Solid State Ionics, 2000, vol. 129, no. 1–4, p. 95.
  10. Iwanschitz, B., Sfeir, J., Mai, A., and Schütze, M., Degradation of SOFC anodes upon redox cycling: a comparison between Ni/YSZ and Ni/CGO, J. Electrochem. Soc., 2010, vol. 157, no. 2, p. B269.
  11. Will, J., Mitterdorfer, A., Kleinlogel, C., Perednis, D., and Gauckler, L., Fabrication of thin electrolytes for second-generation solid oxide fuel cells, Solid State Ionics, 2000, no. 131, p. 79.
  12. Xiao, Guoliang and Chen, Fanglin, Redox Stable Anodes for Solid Oxide Fuel Cell, Frontiers in Energy Res., 2014, vol. 2, article 18, p. 1.
  13. Dr. de Haart, L.G.J., Solid Oxide Fuel Cells – Integrating Degradation Effects into Lifetime Prediction Models, New Energy World, 2014, p. 7.
  14. Grilo, João P.F., Macedo, Daniel A., Nascimento, Rubens M., and Marques, Fernando M.B., Assessment of NiO-CGO composites as cermet precursors, Solid State Ionics, 2018, vol. 321, p. 120.
  15. Gil, V., Moure, C., & Tartaj, J., Sinterability, microstructures and electrical properties of Ni/Gd-doped ceria cermets used as anode materials for SOFC, J. Europ. Ceram. Soc., 2007, vol. 27, p. 4208.

Supplementary files

Supplementary Files
Action
1. JATS XML
2. Fig. 1. Microphotographs of a NiO/GDC composite anode workpiece obtained by casting (a), 3D printing (b).

Download (132KB)
3. Fig. 2. X-ray diffraction patterns of a 3D-printed sample after sintering at 1400 oC (bottom) and after subsequent recovery at 600 oC (top).

Download (59KB)
4. Fig. 3. Microphotographs of Ni/GDC composite anodes after reduction, obtained: (a) and (c) by casting, (b) and (d) 3D printing, at two magnifications.

Download (247KB)
