Cepstral Analysis of Ultrasonic Echoes Measured by an Antenna Array in Order to Obtain Super-Resolution Images of Reflectors

Мұқаба

Дәйексөз келтіру

Толық мәтін

Ашық рұқсат Ашық рұқсат
Рұқсат жабық Рұқсат берілді
Рұқсат жабық Тек жазылушылар үшін

Аннотация

The digital focusing aperture (DFA) method is widely used to image reflectors during ultrasonic inspection. The reliability of inspection is determined by the quality of the DFA image — resolution and signal-to-noise ratio. To achieve super-resolution of echo signals, which will lead to radial super-resolution of CFA-image of reflectors, various methods are used: maximum entropy method, Bernoulli—Gauss deconvolution, Lucy—Richardson deconvolution, methods of recognition with compression (CS), methods of construction of autoregressive models of signals, etc. To apply these methods, we need to know the impulse response of the ultrasonic inspection system. It can be measured, but you can use methods of “blind” deconvolution, which are used in image and signal processing. For example: the method of eliminating camera blur at its random displacement, maximum correlated kurtosis deconvolution (MCKD), cepstral analysis, etc. In this paper, a cepstral analysis method for super-resolution or for obtaining information about the impulse response of the system is considered to construct an AR spectrum model to obtain the radial super-resolution of CFA images. The performance of the proposed method is confirmed by model experiments.

Толық мәтін

Рұқсат жабық

Авторлар туралы

Evgeny Bazulin

ECHO+ Research and Production Center LLC

Хат алмасуға жауапты Автор.
Email: bazulin@echoplus.ru
Ресей, 8, Tvardovsky St., Moscow, 123458

A. Krylovich

Moscow Power Engineering Institute

Email: bazulin@echoplus.ru
Ресей, 14, Krasnokazarmennaya St., Moscow, 111250

Әдебиет тізімі

  1. Bazulin A.E., Bazulin E.G. Deconvolution of complex echo signals using the maximum entropy method in ultrasonic nondestructive testing // Acoust. J. 2009. No. 6. P. 772—783.
  2. Kormylo J.J., Mendel J.M. Maximum likelihood detection and estimation of Bernoulli-Gaussian processes // IEEE Trans. on Information Theory. 1982. V. 28 (3). P. 482—488.
  3. Breykina K.V., Umnyashkin S.V. Image quality assessment in motion blur compensation using the Lucy-Richardson method // Izv. VUZov. Electronics. 2020. V. 25. No. 2. P. 167—174.
  4. Granichin O.N. Measurement randomization and l1-optimization // Stochastic Optimization in Informatics. 2009. No. 5. P. 3—23.
  5. Bazulin E.G. Application of recognition with compression for achieving super-resolution of echo signals // Defectoscopiya. 2022. No. 5. P. 24—36.
  6. Marple Jr. S.L. Digital Spectral Analysis. Moscow: Mir, 1990. 584 p.
  7. Box G.E., Jenkins G.M. Time Series Analysis: Forecasting and Control // San Francisco: Holden-Day, 1970. 553 p.
  8. Bazulin E.G. Processing of TOFD echo signals to achieve super-resolution // Defectoscopiya. 2021. No. 5. P. 13—21.
  9. Bazulin E.G. Increasing the signal-to-noise ratio by combining extrapolation and spectrum splitting methods // Defectoscopiya. 2006. No. 1. P. 68—78.
  10. Fergus R., Singh B., Hertzmann A., Roweis S.T., Freeman W.T. Removing camera shake from a single photograph. ACM SIGGRAPH 2006 Papers on — SIGGRAPH ’06. doi: 10.1145/1179352.1141956.
  11. Wiggins R.A. Minimum entropy deconvolution // GeoExploration. 1978. V. 16. No. 1—2. P. 21—35.
  12. McDonald G.L., Zhao Q. Multipoint optimal minimum entropy deconvolution and convolution fix: application to vibration fault detection // Mechanical Systems and Signal Processing. 2017. V. 82. P. 461—477.
  13. Bogert B.P., Healy M.J.R., Tukey J.W. The quefrency analysis of time series for echoes: Cepstrum, pseudo-autocovariance, cross-cepstrum, and saphe cracking / Proceedings of the Symposium on Time Series Analysis by Rosenblatt M. 1963. P. 209—243.
  14. Bharadwaj P., Demanet L., Fournier A. Focused Blind Deconvolution // IEEE Transactions on Signal Processing. 2019. V. 67. No. 12. P. 3168—3180. DOI: http://dx.doi.org/10.13140/RG.2.2.11028.81285
  15. Scientific and Production Center “ECHO+”: official website. URL: https://echoplus.ru/ (accessed: 11.09.2024).
  16. Shristi Mishra, Deepika Sharma. A review on curvelets and its applications. In: Raju Pal and Praveen Kumar Shukla (eds). SCRS Conference Proceedings on Intelligent Systems, SCRS, India, 2022. P. 213—220. https://doi.org/10.52458/978-93-91842-08-6-20
  17. Bazulin E.G. Application of CF and DMAS technology to improve the quality of reflector images reconstructed from echo signals measured by an antenna array // Defectoscopiya. 2024. No. 12. P. 14—29.

Қосымша файлдар

Қосымша файлдар
Әрекет
1. JATS XML
Жүктеу
2. Fig. 1. Obtaining radial super-resolution by extrapolating the echo spectrum using the AR model.

Жүктеу (113KB)
Метадеректер
3. Fig. 2. Initial echoes (a) and their cepstr (b).

Жүктеу (268KB)
Метадеректер
4. Fig. 3.

Жүктеу (166KB)
Метадеректер
5. Fig. 4. Ideal impulse response s (t) (red graph), impulse response estimate s^ (t) (black graph) - (a); modulus of spectrum s (t) (red graph), modulus of s^ (t) (black graph) - (b); modulus of original echoes (blue graph), extrapolation result using s (t) (red graph) and extrapolation result using s^ (t) (black graph) - (c).

Жүктеу (253KB)
Метадеректер
6. Fig. 5. Impulse responses (a), modulus (b) and phase (c) of their spectra obtained during antenna array acceptance (plots in red) and after cepstral analysis (plots in black).

Жүктеу (236KB)
Метадеректер
7. Fig. 6. Result of echo processing after AR spectrum model construction when inverse filtering is performed using the measured impulse response (red graphs) and the one obtained after cepstral analysis (black graphs).

Жүктеу (264KB)
Метадеректер
8. Fig. 7. Echoes of 33 shots after building an AR model of the spectrum while performing inverse filtering using the measured impulse response (a) and the one obtained after cepstral analysis (b).

Жүктеу (357KB)
Метадеректер
9. Fig. 8. CFA images of two transverse-wave BCOs reconstructed from the measured echoes (a), from the echoes after building an AR model of the spectrum while performing inverse filtering using the measured impulse response (b) and obtained after cepstral analysis (c).

Жүктеу (515KB)
Метадеректер
10. Fig. 9. Impulse response (a) and spectrum modulus (b) obtained during antenna array acceptance (red coloured lines) and after cepstral analysis (black coloured lines).

Жүктеу (246KB)
Метадеректер
11. Fig. 10. CFA images of the transverse wave crack model reconstructed from the measured echoes (a), from the echoes after building an AR spectrum model by performing inverse filtering using the measured impulse response (b) and obtained after cepstral analysis (c).

Жүктеу (784KB)
Метадеректер
12. Fig. 11. CFA-CF images of the crack model, similar to those in Fig. 10b and c, reconstructed on the transverse wave.

Жүктеу (307KB)
Метадеректер
13. Fig. 12. CFA images of the longitudinal wave crack model reconstructed from the measured echoes (a), from the echoes after building the AR spectrum model by inverse filtering using the measured impulse response (b) and obtained after cepstral analysis (c).

Жүктеу (755KB)
Метадеректер
14. Fig. 13. CFA-CF images of the crack model, similar to those in Fig. 12b and c, reconstructed on the longitudinal wave.

Жүктеу (344KB)
Метадеректер
