Экспериментальные исследования по контролю трещин на резьбовых поверхностях методом электромагнитной термографии

Обложка

Цитировать

Полный текст

Открытый доступ Открытый доступ
Доступ закрыт Доступ предоставлен
Доступ закрыт Только для подписчиков

Аннотация

Резьбовые соединения, являясь важным типом соединений, в процессе производства и эксплуатации довольно часто оказываются подвержены образованию трещин на резьбовых поверхностях, что может привести к механическому разрушению. Сложная геометрия резьбовых соединений создает большие проблемы для традиционных методов неразрушающего контроля (НК). Таким образом, важным является разработка продвинутой и отвечающей современным требованиям методики неразрушающего контроля для обнаружения трещин на резьбовых поверхностях. В данном исследовании изучается применимость электромагнитной термографии (ЭМТ) для контроля трещин. Принцип контроля был рассмотрен на основе законов электромагнитной индукции и теплопроводности. Эксперименты проводились на четырех болтах с трещинами на резьбовых поверхностях с использованием методики ЭМТ. Эффективность ЭМТ была подтверждена анализом термограмм и температурных откликов. Кроме того, мы изучили влияние нескольких ключевых параметров, включая ориентацию катушки возбуждения, расположение катушки возбуждения, амплитуду тока возбуждения и размер трещины, на результаты контроля. Полученные результаты свидетельствуют о том, что ЭМТ представляет собой эффективный и практичный метод обнаружения трещин на резьбовых поверхностях.
