Features of Dynamics and Instability of Plasma Jets Expanding into an External Magnetic Field in Laboratory Experiments with Compact Coaxial Plasma Generators on a Large-Scale “Krot” Stand

S. V. Korobkov; Коробков С. В.; A. S. Nikolenko; Николенко А. С.; M. E. Gushchin; Гущин М. Е.; A. V. Strikovsky; Стриковский А. В.; I. Yu. Zudin; Зудин И. Ю.; N. A. Aidakina; Айдакина Н. А.; I. F. Shaikhislamov; Шайхисламов И. Ф.; M. S. Rumenskikh; Руменских М. С.; R. S. Zemskov; Земсков Р. С.; M. V. Starodubtsev; Стародубцев М. В.

doi:10.31857/S0004629923010036

Features of Dynamics and Instability of Plasma Jets Expanding into an External Magnetic Field in Laboratory Experiments with Compact Coaxial Plasma Generators on a Large-Scale “Krot” Stand

作者: Korobkov S.V.¹, Nikolenko A.S.¹, Gushchin M.E.¹, Strikovsky A.V.¹, Zudin I.Y.¹, Aidakina N.A.¹, Shaikhislamov I.F.², Rumenskikh M.S.², Zemskov R.S.¹, Starodubtsev M.V.¹
隶属关系:
1. Institute of Applied Physics, Russian Academy of Sciences
2. Institute of Laser Physics Siberian Branch of the Russian Academy of Sciences
期: 卷 100, 编号 1 (2023)
页面: 107-118
栏目: Articles
URL: https://kazanmedjournal.ru/0004-6299/article/view/647542
DOI: https://doi.org/10.31857/S0004629923010036
EDN: https://elibrary.ru/NPODLB
ID: 647542

如何引用文章

全文:

开放存取

##reader.subscriptionAccessGranted##
受限制的访问

订阅存取

详细
作者简介
参考
补充文件
统计

详细

Structural instabilities that develop during pulsed injection of dense plasma jets into vacuum in the presence of an external quasi-homogeneous magnetic field are studied by high-speed photography using ICCD cameras. The experiments are carried out in the chamber of the “Krot” stand, which has record-breaking dimensions in its class of installations (diameter—3 m, length of the working section—10 m), and makes it possible to study plasma dynamics by various diagnostic methods at scales of more than 1 m both along the magnetic field and in the direction transverse to the magnetic field. During injection along the magnetic field, a transverse collimation of the flow of ionized matter and the development of a flute instability of the plasma boundary are observed, which, at the late stages of expansion, leads to the plasma leaving the injection region in the form of several jets across the field. During transverse injection, the formation of a collimated flow, a “plasma sheet,” is observed, in which, as the plasma moves across the field, inhomogeneous structures develop in the direction of injection.

关键词

laboratory modeling, laboratory astrophysics, magnetohydrodynamics, jet, flute instability

参考

K. Burdonov, R. Bonito, T. Giannini, et al., Astron. and Astrophys. 648, A81 (2021).
K. Burdonov, W. Yao, A. Sladkov, et al., Astron. and Astrophys. 657, A112 (2022).
А. А. Соловьев, К. Ф. Бурдонов, А. В. Котов и др., Известия ВУЗов. Радиофизика 63, 973 (2020).
H. C. Spruit, T. Foglizzo and R. Stehle, Monthly Not. Roy. Astron. Soc. 288, 333 (1997).
S. Matt, R. Winglee and K. H. Böhm, Monthly Not. Roy. Astron. Soc. 345, 660 (2003).
B. Albertazzi, A. Ciardi, M. Nakatsutsumi, et al., Science 346, 325 (2014).
D. P. Higginson, G. Revet, B. Khiar, et al., High Energy Density Physics 23, 48 (2017)
D. D. Ryutov, Phys. of Plasmas 25, 100501 (2018)
Ю. П. Захаров, А. М. Оришич, А. Г. Пономаренко и др., Физика плазмы 12 (10), 1170, (1986).
Ю. П. Захаров, В. М. Антонов, Э. Л. Бояринцев и др., Физика плазмы 32 (3), 207 (2006).
Y. P. Zakharov, IEEE Transactions on Plasma Science 31, 1243, (2003).
J. Bonde, S. Vincena, W. Gekelman, Phys. of Plasmas 25, 042110 (2018).
M. VanZeeland, W. Gekelman, Phys. of Plasmas 11, 320 (2004).
A. Fazzini, W. Yao, K. Burdonov, et al., Astron. Astrophys. 665, A87 (2022)
B. A. Remington, R. P. Drake, D. D. Ryutov, Rev. Mod. Phys. 78, 755 (2006)
В. С. Бескин, В. И. Крауз, С. А. Ламзин, УФН 10, (2022, принята в печать).
P. M. Bellan, X. Zhai, K. B. Chai, B. N. Ha, J. Plasma Phys. 81, 495810502 (2015).
T. C. Underwood, K. T. Loebner, V. A. Miller, et al., Sci. Rep. 9, 1 (2019).
Y. P. Zakharov, A. G. Ponomarenko, V. A. Terekhin, et al. Quantum Electron. 49, 181 (2019)
Y. P. Zakharov, V. P. Neznamov, V. A. Terekhin, et al., J. Phys.: Conference Series 2067, 012021 (2020)
J. Marshall, Phys. of Fluids 3, 134 (1960).
H. W. Friedman, R. M. Patrick, Phys. of Fluids 14, 1889 (1971).
Б. Г. Гаврилов, С. А. Кожухов, Д. Б. Собянин, ЖТФ 64, 6 (1994).
С. В. Коробков, М. Е. Гущин, В. И Гундорин и др., Письма в ЖТФ 45, 45 (2019).
Н. А. Айдакина, А. Г. Галка, В. И. Гундорин и др., Геомагнетизм и аэрономия 58, 331 (2018).
Y. Zhang, D. M. Fisher, M. Gilmore, et al., Phys. Plasmas 25, 055709 (2018)
М. Е. Гущин, С. В. Коробков, В. А. Терехин и др., Письма в ЖЭТФ 108, 416 (2018).
B. Khiar, G. Revet, A. Ciardi, et al., Phys. Rev. Lett. 20, 205001 (2019).
P. J. Armitage, M. Livio, J. E. Pringle, Monthly Not. Roy. Astron. Soc. 324, 3, 705 (2001).
P. J. Armitage, Monthly Not. Roy. Astron. Soc. 274, 1242 (1995).
P. J. Armitage, Astrophys. Lett. 833, L15 (2016).
C. Argiroffi, J. J. Drake, R. Bonito, et al., Astron. and Astrophys. 607, A14 (2017).
D. Ryutov, B. Remington, H. Robey, et al., Phys. of Plasmas 8, 1804 (2001).
D. Ryutov, R. P. Drake, J. Kane, et al., Astrophys. J. 518, 821 (1999).
И. М. Подгорный, Р. З. Сагдеев, УФН 98, 409 (1969).
В. Б. Баранов, Космические исследования 2, 109 (1969).
K. Schindler, Rev. Geophys. 7, 51 (1969).
S. Orlando, F. Reale, G. Peres, et al., Monthly Not. Roy. Astron. Soc. 415, 3380 (2011).
M.M. Romanova, G. V. Ustyugova, A. V. Koldoba, et al., Astrophys. J. 578, 420 (2002).
T. Giannini, S. Antoniucci, D. Lorenzetti, et al., Astrophys. J. 839, 112 (2017).
P. Hartigan, A. Frank, P. Varniere, et al., Astrophys. J. 661, 910 (2007).
T. P. Ray, T. W. B. Muxlow, D. J. Axon, et al., Nature 385, 415 (1997).
J. A. Morse, P. Hartigan, G. Cecil, et al., Astrophys. J. 399, 231 (1992).
